T-REX -3/3.6/4.6/5/6K HYBRID INVERTER
The T-REX LP1G01 Series Hybrid Solar Inverters are high-efficiency single-phase inverters available in 3kW, 3.6kW, 4kW, 4.6kW, 5kW, and 6kW models for residential solar and energy storage systems. Compatible with lithium-ion and lead-acid batteries, they feature a 40V–60V battery voltage range, dual MPPT technology, support for up to 7.8kW PV input, and IP65-rated protection for indoor and outdoor installation. With intelligent air cooling and advanced energy management, the T-REX LP1G01 Series delivers reliable, efficient, and uninterrupted power for hybrid and backup applications.
₦0.00
The T-REX LP1G01 Series Hybrid Solar Inverters are advanced single-phase energy storage solutions designed to deliver exceptional efficiency, intelligent power management, and reliable performance for residential solar systems. Available in 3kW, 3.6kW, 4kW, 4.6kW, 5kW, and 6kW models, this series offers flexible power options to meet a wide range of household energy requirements.
Compatible with both lithium-ion and lead-acid batteries, the T-REX LP1G01 Series supports a 40V–60V battery voltage range, making it suitable for a variety of energy storage systems. With charging and discharging currents of up to 120A (depending on the model) and power ratings up to 6,000W, these inverters ensure fast battery charging, efficient energy storage, and dependable backup power.
Designed to maximize solar energy production, the series supports up to 7,800W of recommended PV input and features dual MPPT trackers (2 MPPTs / 1 string per tracker) for improved energy harvesting, even when solar panels are installed at different orientations or experience partial shading.
The T-REX LP1G01 Series operates on a 230V AC single-phase electrical system with an 184–264.5V AC input voltage range, providing stable performance under varying grid conditions. Built with an IP65-rated enclosure, the inverter is protected against dust and water ingress, making it suitable for both indoor and outdoor installations. Its advanced natural and intelligent air cooling system ensures efficient thermal management, quiet operation, and enhanced long-term reliability.
Whether used in hybrid solar installations, self-consumption systems, or backup power applications, the T-REX LP1G01 Series delivers intelligent energy management, high conversion efficiency, and dependable performance for modern homes.
Key Features
- Available in 3kW, 3.6kW, 4kW, 4.6kW, 5kW, and 6kW models
- Models: T-REX-3KLP1G01, T-REX-3K6LP1G01, T-REX-4KLP1G01, T-REX-4K6LP1G01, T-REX-5KLP1G01, and T-REX-6KLP1G01
- Compatible with Lithium-ion and Lead-acid batteries
- 40V–60V battery voltage range
- Up to 120A charging/discharging current
- Supports up to 7,800W recommended PV input
- Dual MPPT (2 MPPTs / 1 string per tracker) for optimized solar harvesting
- 230V AC single-phase input
- 184–264.5V AC input voltage range
- IP65-rated enclosure for indoor and outdoor installation
- Natural and intelligent air cooling for efficient thermal management
- Ideal for residential hybrid solar, energy storage, and backup power systems
- High efficiency, intelligent energy management, and reliable long-term performance.
